GIGABYTE B560M DS3H Intel B560 LGA 1200 Micro-ATX Motherboard

GIGABYTE B560M DS3H Intel B560 LGA 1200 Micro-ATX Motherboard

Brand: GIGABYTE
Rs. 12,999.00
15% off Rs. 12,999.00 Sale Sold out Rs. 15,200.00
  • GIGABYTE B560M DS3H Micro-ATX DDR4 motherboard is designed to support latest Intel Socket LGA 1200 for 11th and 10th Gen Intel Core processors and Pentium Gold and Celeron Processors.
  • The GIGABYTE B560 motherboard is PCIe 4.0 Ready supporting up to 128GB DDR4 4600MHz of memory and Intel Extreme Memory Profile (XMP). The DDR4 GIGABYTE motherboard support next gen PCIe 4.0 slots.
  • Enjoy extended connectivity with the next-gen technology of PCIe 4.0, Realtek Ethernet, M.2 Slots, USB 3.2 Gen 1 connector, USB-C and more.

~section~

Model GIGABYTE B560M DS3H Micro-ATX Motherboard
CPU Support Supports 11th & 10th Gen i9/i7/i5/i3 Intel Core Processors, Pentium Gold and Celeron Processors
CPU Socket LGA 1200
Chipset Intel B560 Express Chipset
Form Factor Micro-ATX
Memory 4x DDR4 memory slots, supporting up to 128GB
4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) /
3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) /
3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
Supports Dual-Channel mode
Supports Intel Extreme Memory Profile (XMP)
Expansion Slot 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
2 x PCI Express x1 slot, supporting PCIe 3.0
Onboard Graphics 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
Storage 1 x M.2 connector
6 x SATA 6Gb/s connectors
USB 1 x USB Type-C
5 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
LAN Realtek GbE LAN chip (1000/100 Mbit)
Audio Realtek Audio Codec
BackPanel Ports 2 x USB 2.0/1.1 ports
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x DisplayPort
1 x HDMI port
3 x USB 3.2 Gen 1 ports
1 x USB Type-C port, with USB 3.2 Gen 1 support
1 x RJ-45 port
3 x audio jacks
Internal I/O Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x parallel port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Operating System Support for Windows 11 64-bit, Windows 10 64-bit
Dimension Micro-ATX
24.4cm x 22.5cm
Warranty 3 Years Brand Warranty
